Output control

This operation provides control of the output printout It affects only the dimat part of the output.

Input format


OUTPut control ...................(up to 80 characters)


nopt

Parameter definitions

nopt

0 $\parbox{10cm}{ all output is supressed (except error messages)}$

1 $\parbox{10cm}{ The main results of the computation only are printed}$

2 $\parbox{10cm}{ The main results and the input data are printed}$

3 $\parbox{10cm}{ All output is printed}$

4 $\parbox{10cm}{ Used for short printing of tracking results when such printing can be used for input to plotting programs.}$

14 $\parbox{10cm}{ Same as 4 . The fifth coordinate will then be the phase relative to an RF cavity instead of the path length.}$

Note : $\parbox{10cm}{not all output is affected by the option 14 in the ... ... suppress printout and the NOECHO can be reversed by use of the command ECHO.}$

Examples

All three examples come from demo6 and demo7 where they are use extensively to reduce the amount of output produced by the program.

OUTPUT CONTROL
3,

OUTPUT CONTROL
1,

OUTPUT CONTROL
0,
